In this tutorial, we build an advanced agentic Deep Reinforcement Learning system that guides an agent to learn not only actions within an environment but also how to choose its own training strategies. We design a Dueling Double DQN learner, introduce a curriculum with increasing difficulty, and integrate multiple exploration modes that adapt as training evolves. Most importantly, we construct a meta-agent that plans, evaluates, and regulates the entire learning process, allowing us to experience how agency transforms reinforcement learning into a self-directed, strategic workflow. Check out the FULL CODES here.
import gymnasium as gym
import numpy as np
import torch, torch.nn as nn, torch.optim as optim
from collections import deque, defaultdict
import math, random, matplotlib.pyplot as plt
random.seed(0); np.random.seed(0); torch.manual_seed(0)
class DuelingQNet(nn.Module):
def __init__(self, obs_dim, act_dim):
super().__init__()
hidden = 128
self.feature = nn.Sequential(
nn.Linear(obs_dim, hidden),
nn.ReLU(),
)
self.value_head = nn.Sequential(
nn.Linear(hidden, hidden),
nn.ReLU(),
nn.Linear(hidden, 1),
)
self.adv_head = nn.Sequential(
nn.Linear(hidden, hidden),
nn.ReLU(),
nn.Linear(hidden, act_dim),
)
def forward(self, x):
h = self.feature(x)
v = self.value_head(h)
a = self.adv_head(h)
return v + (a – a.mean(dim=1, keepdim=True))
class ReplayBuffer:
def __init__(self, capacity=100000):
self.buffer = deque(maxlen=capacity)
def push(self, s,a,r,ns,d):
self.buffer.append((s,a,r,ns,d))
def sample(self, batch_size):
batch = random.sample(self.buffer, batch_size)
s,a,r,ns,d = zip(*batch)
def to_t(x, dt): return torch.tensor(x, dtype=dt, device=device)
return to_t(s,torch.float32), to_t(a,torch.long), to_t(r,torch.float32), to_t(ns,torch.float32), to_t(d,torch.float32)
def __len__(self): return len(self.buffer)
We set up the core structure of our deep reinforcement learning system. We initialize the environment, create the dueling Q-network, and prepare the replay buffer to store transitions efficiently. As we establish these foundations, we prepare everything our agent needs to begin learning. Check out the FULL CODES here.
def __init__(self, obs_dim, act_dim, gamma=0.99, lr=1e-3, batch_size=64):
self.q = DuelingQNet(obs_dim, act_dim).to(device)
self.tgt = DuelingQNet(obs_dim, act_dim).to(device)
self.tgt.load_state_dict(self.q.state_dict())
self.buf = ReplayBuffer()
self.opt = optim.Adam(self.q.parameters(), lr=lr)
self.gamma = gamma
self.batch_size = batch_size
self.global_step = 0
def _eps_value(self, step, start=1.0, end=0.05, decay=8000):
return end + (start – end) * math.exp(-step/decay)
def select_action(self, state, mode, strategy, softmax_temp=1.0):
s = torch.tensor(state, dtype=torch.float32, device=device).unsqueeze(0)
with torch.no_grad():
q_vals = self.q(s).cpu().numpy()[0]
if mode == “eval”:
return int(np.argmax(q_vals)), None
if strategy == “epsilon”:
eps = self._eps_value(self.global_step)
if random.random() < eps:
return random.randrange(len(q_vals)), eps
return int(np.argmax(q_vals)), eps
if strategy == “softmax”:
logits = q_vals / softmax_temp
p = np.exp(logits – np.max(logits))
p /= p.sum()
return int(np.random.choice(len(q_vals), p=p)), None
return int(np.argmax(q_vals)), None
def train_step(self):
if len(self.buf) < self.batch_size:
return None
s,a,r,ns,d = self.buf.sample(self.batch_size)
with torch.no_grad():
next_q_online = self.q(ns)
next_actions = next_q_online.argmax(dim=1, keepdim=True)
next_q_target = self.tgt(ns).gather(1, next_actions).squeeze(1)
target = r + self.gamma * next_q_target * (1 – d)
q_vals = self.q(s).gather(1, a.unsqueeze(1)).squeeze(1)
loss = nn.MSELoss()(q_vals, target)
self.opt.zero_grad()
loss.backward()
nn.utils.clip_grad_norm_(self.q.parameters(), 1.0)
self.opt.step()
return float(loss.item())
def update_target(self):
self.tgt.load_state_dict(self.q.state_dict())
def run_episodes(self, env, episodes, mode, strategy):
returns = []
for _ in range(episodes):
obs,_ = env.reset()
done = False
ep_ret = 0.0
while not done:
self.global_step += 1
a,_ = self.select_action(obs, mode, strategy)
nobs, r, term, trunc, _ = env.step(a)
done = term or trunc
if mode == “train”:
self.buf.push(obs, a, r, nobs, float(done))
self.train_step()
obs = nobs
ep_ret += r
returns.append(ep_ret)
return float(np.mean(returns))
def evaluate_across_levels(self, levels, episodes=5):
scores = {}
for name, max_steps in levels.items():
env = gym.make(“CartPole-v1″, max_episode_steps=max_steps)
avg = self.run_episodes(env, episodes, mode=”eval”, strategy=”epsilon”)
env.close()
scores[name] = avg
return scores
We define how our agent observes the environment, chooses actions, and updates its neural network. We implement Double DQN logic, gradient updates, and exploration strategies that let the agent balance learning and discovery. As we finish this snippet, we equip our agent with its full low-level learning capabilities. Check out the FULL CODES here.
def __init__(self, agent):
self.agent = agent
self.levels = {
“EASY”: 100,
“MEDIUM”: 300,
“HARD”: 500,
}
self.plans = []
for diff in self.levels.keys():
for mode in [“train”, “eval”]:
for expl in [“epsilon”, “softmax”]:
self.plans.append((diff, mode, expl))
self.counts = defaultdict(int)
self.values = defaultdict(float)
self.t = 0
self.history = []
def _ucb_score(self, plan, c=2.0):
n = self.counts[plan]
if n == 0:
return float(“inf”)
return self.values[plan] + c * math.sqrt(math.log(self.t+1) / n)
def select_plan(self):
self.t += 1
scores = [self._ucb_score(p) for p in self.plans]
return self.plans[int(np.argmax(scores))]
def make_env(self, diff):
max_steps = self.levels[diff]
return gym.make(“CartPole-v1”, max_episode_steps=max_steps)
def meta_reward_fn(self, diff, mode, avg_return):
r = avg_return
if diff == “MEDIUM”: r += 20
if diff == “HARD”: r += 50
if mode == “eval” and diff == “HARD”: r += 50
return r
def update_plan_value(self, plan, meta_reward):
self.counts[plan] += 1
n = self.counts[plan]
mu = self.values[plan]
self.values[plan] = mu + (meta_reward – mu) / n
def run(self, meta_rounds=30):
eval_log = {“EASY”:[], “MEDIUM”:[], “HARD”:[]}
for k in range(1, meta_rounds+1):
diff, mode, expl = self.select_plan()
env = self.make_env(diff)
avg_ret = self.agent.run_episodes(env, 5 if mode==”train” else 3, mode, expl if mode==”train” else “epsilon”)
env.close()
if k % 3 == 0:
self.agent.update_target()
meta_r = self.meta_reward_fn(diff, mode, avg_ret)
self.update_plan_value((diff,mode,expl), meta_r)
self.history.append((k, diff, mode, expl, avg_ret, meta_r))
if mode == “eval”:
eval_log[diff].append((k, avg_ret))
print(f”{k} {diff} {mode} {expl} {avg_ret:.1f} {meta_r:.1f}”)
return eval_log
We design the agentic layer that decides how the agent should train. We use a UCB bandit to select difficulty levels, modes, and exploration styles based on past performance. As we repeatedly run these choices, we observe the meta-agent strategically guiding the entire training process. Check out the FULL CODES here.
obs_dim, act_dim = tmp_env.observation_space.shape[0], tmp_env.action_space.n
tmp_env.close()
agent = DQNAgent(obs_dim, act_dim)
meta = MetaAgent(agent)
eval_log = meta.run(meta_rounds=36)
final_scores = agent.evaluate_across_levels(meta.levels, episodes=10)
print(“Final Evaluation”)
for k, v in final_scores.items():
print(k, v)
We bring everything together by launching meta-rounds where the meta-agent selects plans and the DQN agent executes them. We track how performance evolves and how the agent adapts to increasingly difficult tasks. As this snippet runs, we see the emergence of long-horizon self-directed learning. Check out the FULL CODES here.
for diff, color in [(“EASY”,”tab:blue”), (“MEDIUM”,”tab:orange”), (“HARD”,”tab:red”)]:
if eval_log[diff]:
x, y = zip(*eval_log[diff])
plt.plot(x, y, marker=”o”, label=f”{diff}”)
plt.xlabel(“Meta-Round”)
plt.ylabel(“Avg Return”)
plt.title(“Agentic Meta-Control Evaluation”)
plt.legend()
plt.grid(True, alpha=0.3)
plt.tight_layout()
plt.show()
We visualize how the agent performs across Easy, Medium, and Hard tasks over time. We observe learning trends, improvements, and the effects of agentic planning reflected in the curves. As we analyze these plots, we gain insight into how strategic decisions shape the agent’s overall progress.
In conclusion, we observe our agent evolve into a system that learns on multiple levels, refining its policies, adjusting its exploration, and strategically selecting how to train itself. We observe the meta-agent refine its decisions through UCB-based planning and guide the low-level learner toward more challenging tasks and improved stability. With a deeper understanding of how agentic structures amplify reinforcement learning, we can create systems that plan, adapt, and optimize their own improvement over time.
